Milling insert WNMX160720ZNN-MM PC3700 KORLOY
SKU
34000134
Availability:
On order
VAT will be added to the product price.
Milling insert
- Nose-R: security of rigid edge in ramping pocket machining, round edge suitable for high feed rates insert geometry, possible to use R/L machining.
- Optimal grades for most workpieces makes high efficiency cutting possible.
- Clamping surface: design for stable clamping, prevention of friction by chip.
- Minor cutting edge: improvement of surface roughness in high feed machining, special design for decreasing thrust force, symmetrical insert design for R/L type tool.
- Chip breaker: reduction of cutting load due to high rake angle, improvement of chip flow and evacuation in various applications, prevention of damage on clamping face of insert.
- Major cutting edge: symmetrical design insert for R/L type tool, superior cutting performance due to high rake angle cutting edge, low cutting resistance in high feed, special design for decreasing thrust force.
| Grade | ISO | Features |
|---|---|---|
| PC3700 | P25-P35 | Exclusive grade for milling applications. Lubricated and high hardness multi-layered coating. Excellent chip removal rate due to a tough substrate specialized for steel and lubricative PVD coating of high-hardness. A highly chipping-resistant grade for minimised deviation and extended tool life under various cutting conditions. |
